R900809783
7HSR10-15/01C FE//ZN8//CN/T0

7HSR10-15/01C FE//ZN8//CN/T0
  • Availability: on request
  • Weight: 30.00 KG
  • Part number: R900809783
  • Manufacturer: Bosch Rexroth

Price:

remove add

The minimum order quantity for the product is 1.

7HSR10-15/01C FE//ZN8//CN/T0
Quantity discount

The price will be automatically updated once added to the cart.

Physical size and weight
Net weight 30 kg
Operating pressure, max. 315 bar
Other properties
ECLASS_13_Classification 51-47-01-02
Product family HSR 10
Port size G1/2
Size 10
Hydraulic fluid HL,HLP,HVLP
Surface coating Galvanic coating EN ISO 19598
Description

Compact hydraulic controls for 7 vertical stackings of size 10

Features
  • Base element for ready-for-connection controls in vertical stacking design
  • Compacter hydraulic control block
  • Common pump and tank line
  • Separate actuator ports of the stations
