R930007140
05443313043500D VBSO-DE33-FC2PLVUR-34-3&

R930007140
  • Availability: on request
  • Weight: 2.20 KG
  • Part number: R930007140
  • Manufacturer: Bosch Rexroth

Price:

remove add

The minimum order quantity for the product is 5.

R930007140
Quantity discount

The price will be automatically updated once added to the cart.

Physical size and weight
Adjustable pressure range 150-350
Max. flow 150 l/min
Net weight 2.2 kg
Nominal flow 150 l/min
Operating pressure, max. 210 bar
Pressure pre-setting With pressure pre-setting
Pressure setting 350 bar
Other properties
Direct - Pilot External pilot operated
Hydraulic fluid HL,HLP
Pilot ratio 4:1
Ports Special flange
Ports number 5
Product family VBSO-DE-33-FC2
Product family Double effect
Product family classification Dual counterbalance
Product family type VBSO
Product type VBSO-33
Sealing material NBR
Type of connection Flange connection
Features
  • Maximum operating pressure 210 bar (3000 psi)
  • Maximum flow 150 l/min (40 gpm)
  • Flangeable
