Physical size and weight
| Net weight |
0.8
kg |
| Width of runner block |
48
mm |
| Outer diameter D |
19
mm |
Other properties
| Accessories for |
Guide rail
|
| Nominal size |
25
|
| Product information |
for preload class C3
|
| Dimension A (profiled rail systems) |
48
mm |
| Dimension B1 |
81.5
mm |
| Dimension B3 |
115
mm |
| Dimension D |
19
mm |
Description
Mounting runner block for roller runner block
Preload class C3
Size 25
Features
- Assembly aid for highly accurate parallel alignment of ball rail systems (types SNS and SNO)
Manual (2)
Roller rail systems High Precision RSHP
(EN)
|
Sign in
|
|
R182922090
