| Compatible |
EMC, CKK, CKR, MKK, MKR, MLR, OBB, AGK, VKK, TKL, PSK
|
| Connection type 1 |
2 X female connectors, straight, M8x1, 3-pin, self-locking screw thread
|
| Connection type 2 |
Male connector, straight, M12x1, 4-pin, self-locking screw thread
|
| Electrical accessories for electromechanical cylinders |
Passive distributor
|
| Electrical accessories for linear axes |
Passive distributor
|
| Function indicator |
no
|
| Maximum operating current per contact |
4
A |
| Note on protection class |
inserted & screwed down
|
| Operating voltage (min. … max.) |
32 V
|
| Operating voltage indicator |
no
|
| Permissible ambient temperature (min. ... max.) |
-25 °C ... +85 °C
|
| Protection class |
IP67
|
| Use |
Adapter or distributor
|
| Version |
straight, for 1 - 2 sensors
|
