R901086610
Z1S6P30-4X/VSO68

R901086610
  • Availability: on request
  • Weight: 0.76 KG
  • Part number: R901086610
  • Manufacturer: Bosch Rexroth

Price:

remove add

The minimum order quantity for the product is 0.

R901086610
Quantity discount

The price will be automatically updated once added to the cart.

Physical size and weight
Net weight 760 g
Operating pressure, max. 350 bar
Max. flow 40 l/min
Other properties
Connection diagram ISO 4401-03-02-0-05
ECLASS_13_Classification 51-44-04-01
Product family Z1S6
Spool symbol P2 → P1
Type of connection Sandwich plate
Size 6
Type of actuation with mechanical actuation
Number of ports 4
Number of switching positions 2
Electrical connection description 0
Hydraulic fluid HL,HLP,HLPD,HVLP,HVLPD,HETG,HEES,HEPG,HFDU,HFDR
Seals FKM
Description

Industrial hydraulic valve in a high performance range. Reliable blocking of the oil flow according to the hydraulic symbol

Features
  • Direct actuated
  • Leakage-free blocking in channel P
  • Cracking pressure 3 bar
  • Special type 68
Manual (2)
PDF 472f764a-5bf5-4b93-87a6-9360c0070d4d_original (EN)
PDF a1cdff16-1354-4150-a8c3-1339d7a836f0_original (EN)
DataSheet (1)
PDF Check valve (EN)
Pos Name Material Number
998 REPAIR KIT
Z1S6.-4X/
 R961014577
999 SEAL KIT
06A-VR/RN 5FACH
 R961000838
