R901454050
S8A00-1X/450J3

R901454050
  • Availability: 2 weeks
  • Weight: 0.20 KG
  • Part number: R901454050
  • Manufacturer: Bosch Rexroth

Price:

remove add

The minimum order quantity for the product is 0.

R901454050
Quantity discount

The price will be automatically updated once added to the cart.

Physical size and weight
Max. flow 36 l/min
Net weight 198 g
Operating pressure, max. 450 bar
Other properties
Connection diagram Pipe thread "G" according to ISO 228-1
ECLASS_13_Classification 51-44-04-01
Hydraulic fluid HL,HLP,HLPD,HVLP,HVLPD,HETG,HEES,HEPG,HFDU (glycol base),HFDU (ester base),HFC (Fuchs: Hydrotherm 46M, Petrofer: Ultra Safe 620)
Product family S.A
Seals NBR
Size 8
Spool symbol A → B
Type of actuation with mechanical actuation
Type of connection Threaded connection
Valve ports number 2
Valve position number 2
Description

Industrial hydraulic valve in a high performance range. Reliable switching of the oil flow direction according to hydraulic symbol

Features
  • Check valve
  • Direct actuated
  • Improved corrosion protection
