R901282051
M-3SMR6C3X/420/B18

R901282051
  • Availability: on request
  • Weight: 1.45 KG
  • Part number: R901282051
  • Manufacturer: Bosch Rexroth

Price:

remove add

The minimum order quantity for the product is 0.

R901282051
Quantity discount

The price will be automatically updated once added to the cart.

Physical size and weight
Net weight 1.45 kg
Operating pressure, max. 420 bar
Max. flow 40 l/min
Other properties
Connection diagram ISO 4401-03-02-0-05
ECLASS_13_Classification 51-44-01-01
Product family M-.S.6,10
Spool symbol Symbol C
Type of connection Subplate mounting
Size 6
Type of actuation with manual actuation
Number of ports 3
Number of switching positions 2
Supply voltage -
Hydraulic fluid HL,HLP,HLPD,HVLP,HVLPD
Seals NBR
Description

Industrial hydraulic valve in a high performance range. Reliable switching of the oil flow direction according to hydraulic symbol

Features
  • Seat valve
  • Direct actuated
  • Safe switching also with longer standstill periods under pressure
Manual (2)
PDF 472f764a-5bf5-4b93-87a6-9360c0070d4d_original (EN)
PDF d88d3b98-0d67-4a73-9844-3b437deb3bea_original (EN)
DataSheet (1)
PDF 2/2, 3/2 and 4/2 directional seat valve with mechanical, manual or fluidic operation (EN)
