R930059703
L7102A06AEOB010-SE.VS120-1/4G-A-P1C1-DE&

R930059703
  • Availability: on request
  • Weight: 1.13 KG
  • Part number: R930059703
  • Manufacturer: Bosch Rexroth

Price:

remove add

The minimum order quantity for the product is 5.

R930059703
Quantity discount

The price will be automatically updated once added to the cart.

Physical size and weight
Max. flow 25 l/min
Net weight 1.13 kg
Nominal flow 25 l/min
Operating pressure, max. 310 bar
Other properties
Coil integrated Integrated coil
Direct - Pilot Direct acting
Drain type External drain
Electrical connector DIN 43650 – EN 175301-803
Hydraulic fluid HL,HLP
Ports G 1/4
Ports number 6
Positions 2
Product family VS120
Product family 6 ways
Product family classification 6/2 ways/positions flow diverters
Product family type VS120
Product type VS120
Sealing material NBR
Spool Poppet Spool type
Supply voltage 12 V DC
Type of connection Threaded connection
Features
  • Maximum operating pressure 310 bar (4495 psi)
  • Maximum flow 25 l/min (7 gpm)
  • Size 4
  • Ports: G 1/4
