R932500152
RIT BIDIREZ G1/2 FF 0,5-15BAR

R932500152
  • Availability: on request
  • Weight: 0.80 KG
  • Part number: R932500152
  • Manufacturer: Bosch Rexroth

Price:

remove add

The minimum order quantity for the product is 10.

R932500152
Quantity discount

The price will be automatically updated once added to the cart.

Physical size and weight
Max. flow 50 l/min
Net weight 800 g
Nominal flow 50 l/min
Operating pressure, max. 350 bar
Pressure setting 15 bar
Other properties
Direct - Pilot Direct acting
Hydraulic fluid HL,HLP
Ports G 1/2
Ports number 2
Product family CAB
Product family classification Bi-directional check valves, line mounted double acting poppet type
Product family type CAB
Sealing material NBR
Spool Poppet Poppet type
Type of connection Threaded connection
Features
  • Maximum operating pressure 350 bar (5000 psi)
  • Maximum flow 50 l/min (13 gpm)
  • Port: G 1/2
  • Sleeve for line mounting
